제품 상세 정보:

원래 장소: 광동, 중국
브랜드 이름: LEDKING or OEM & ODM
모델 번호: RO-P481

결제 및 배송 조건:

최소 주문 수량: 1
가격: $243-263
최고의 가격 접촉

상세 정보
픽셀 피치: 4.81mm 픽셀 밀도: 43264 도트/m2
픽셀 구성: 1R1G1B 최대 전력 소비: 40W
패널 중량: 0.65kg 캐비닛 크기: 500*1000mm*90mm, 500*500*90mm
캐비닛 해상도: 104도트 * 208도트, 104도트 * 104도트 패널 수량: 8개, 4개
스크린 전원 공급기: AC110V/220V - 5V60A 최대 전력 용량: 1200W/m2
명도: 3800-4000cd/m2 새로 고침 빈도: 1920-3840 HZ/S
작동 온도: -10°C~45°C 작동 습도: 10-90%
IP 보호 지수: IP65
강조하다:

500*1000mm LED Video Wall

,

2 Years Warranty Rental LED Screen

,

1920Hz-3840Hz Refresh Rate Outdoor LED Display Screen

제품 설명

Outdoor P4.81 500*1000mm Aluminum Cabinet Rental LED Screen
Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 0 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 1
Module Specifications
Feature Outdoor P4.81 Outdoor P5 Outdoor P5
Panel Dimension 250mm(W) * 250mm(H) 160mm(W) * 160mm(H) 320mm(W) * 160mm(H)
Pixel pitch 4.81mm 5mm 5mm
Pixel Density 43264 dot/m2 40000 dot/m2 40000 dot/m2
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD2727/SMD1921 SMD2727 SMD1921
Pixel resolution 52 dot * 52 dot 64 dot * 32 dot 64 dot * 32 dot
Max power consumption 40W 25W 40W
Panel weight 0.65KG 0.25KG 0.45KG
Cabinet Specifications
Feature Outdoor P4.81 Outdoor P5 Outdoor P5
Cabinet size 500*1000mm*90mm, 500*500*90mm 960mm*960mm*90mm 960mm*960mm*90mm
Cabinet Resolution 104 dot * 208 dot, 104 dot * 104 dot 192 dot * 192 dot 192 dot * 192 dot
Quantity of panel 8pcs, 4pcs 36pcs 18pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Diecsting aluminum cabinet Simple Iron/ waterproof iron cabinet Diecsting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 170/ 120 170/ 120 170/ 120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 1200 W/m2 1350W/m2 976W/m2
Average power 600 W/m2 675W/m2 488W/m2
Technical Specifications
Feature Outdoor P4.81 Outdoor P5 Outdoor P5
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/ 13S 1/8S 1/8S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096*4096*4096 4096*4096*4096 4096*4096*4096
Brightness 3800-4000cd/m2 5000-5500 mcd/m2 5000-5500 mcd/m2
Life span 100000Hours 100000Hours 100000Hours
Control distance < 100M < 100M < 100M
Best viewing distance 4-40M 5-40M 5-40M
Operating temperature -10C°~45C° -10C°~45C° -10C°~45C°
Operating Humidity 10-90 % 10-90 % 10-90 %
IP protective index IP65 IP65 IP65
>> Most in Kinglight and 3840 refresh rate, if need to change detail and More Pixel Pitch and technical details, feel free to contact us <<
Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 2 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 3 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 4 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 5 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 6 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 7
Company Profile
Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 8 Outdoor LED Display Screen with 500*1000mm Custom Size Aluminum Cabinet and 2 Years Warranty for High Refresh Rate 1920Hz-3840Hz 9
