제품 상세 정보:

원래 장소: 광동, 중국
브랜드 이름: LEDKING or OEM & ODM
모델 번호: RO-P667

결제 및 배송 조건:

최소 주문 수량: 1
가격: $478-498
최고의 가격 접촉

상세 정보
픽셀 피치: 6.67mm 픽셀 밀도: 22477 도트/m2
픽셀 구성: 1R1G1B 최대 전력 소비: 43w
패널 중량: 0.45kg 캐비닛 크기: 960mm*960mm*90mm
캐비닛 해상도: 144도트*144도트 패널 수량: 18pcs
가장 좋은 관점: 140/ 120 스크린 전원 공급기: AC110V/220V - 5V60A
최대 전력 용량: 1350W/m2 새로 고침 빈도: 1920-3840 HZ/S
명도: 4000-5000cd/m2 최상의 시청 거리: 6~40m
IP 보호 지수: IP65
강조하다:

P6.67 Outdoor LED Display Screen

,

960*960mm LED Video Wall

,

100000Hours Rental LED Screen

제품 설명

Outdoor P6.67 960×960mm Aluminum Cabinet Rental Screen
Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 0 Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 1
Product Specifications
Module Specifications
Feature Outdoor P5 Outdoor P6 Outdoor P6.67
Panel Dimension 320mm(W) × 160mm(H) 192mm(W) × 192mm(H) 320mm(W) × 160mm(H)
Pixel pitch 5mm 6mm 6.67mm
Pixel Density 40000 dot/m² 27777 dot/m² 22477 dot/m²
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD1921 SMD3535 SMD3535
Pixel resolution 64 dot × 32 dot 32 dot × 32 dot 48 dot × 48 dot
Max power consumption 40W 29W 43W
Panel weight 0.45KG 0.35KG 0.45KG
Cabinet Specifications
Feature Outdoor P5 Outdoor P6 Outdoor P6.67
Cabinet size 960mm×960mm×90mm 576mm×576mm×90mm, 768mm×768mm×90mm 960mm×960mm×90mm
Cabinet Resolution 192 dot × 192 dot 96 dot × 96 dot, 128dot×128dot 144dot×144dot
Quantity of panel 18pcs 9pcs, 16pcs 18pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Diecasting aluminum cabinet Diecasting aluminum cabinet Diecasting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 170/120 140/120 140/120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 976W/m² 1050W/m² 1350W/m²
Average power 488W/m² 525W/m² 675W/m²
Technical Specifications
Feature Outdoor P5 Outdoor P6 Outdoor P6.67
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/8S 1/8S 1/6S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096×4096×4096 4096×4096×4096 4096×4096×4096
Brightness 5000-5500 mcd/m² 4000-5000 cd/m² 4000-5000 cd/m²
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 5-40M 6-40M 6-40M
Operating temperature -10°C to 45°C -10°C to 45°C -10°C to 45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP65 IP65 IP65
Contact Us for Custom Specifications
Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 2 Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 3 Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 4 Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 5
Company Profile
Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 6 Outdoor LED Display Screen P6.67 960*960mm Aluminum Cabinet with 256*128/256*256 Dot Resolution and 100000 Hours Lifespan 7
