제품 상세 정보:

원래 장소: 광동, 중국
브랜드 이름: LEDKING or OEM & ODM
모델 번호: FO-P4

결제 및 배송 조건:

최소 주문 수량: 1
가격: $411-431
최고의 가격 접촉

상세 정보
픽셀 피치: 4mm 픽셀 밀도: 62500 도트/m2
픽셀 구성: 1R1G1B 최대 전력 소비: 25W
패널 중량: 0.2kg 캐비닛 크기: 512mm*512mm*85mm
캐비닛 해상도: 128 도트 * 128 도트 명도: 800-1000 cd/m2
새로 고침 빈도: 1920-3840 HZ/S 디스플레이 색상: 4096*4096*4096
수명: 100000 시간 작동 온도: -10°C~45°C
작동 습도: 10-90% IP 보호 지수: IP43
최상의 시청 거리: 4-30m
강조하다:

P4 Pixel Pitch LED Video Wall

,

1920Hz-3840Hz Refresh Rate Digital Signage Display

,

256*128/256*256 dot Resolution Outdoor LED Display Screen

제품 설명

Outdoor P4 1024×768×90mm Waterproof Iron Round Display Advertising Screen
Outdoor LED Display Screen with P4 Pixel Pitch 1920Hz-3840Hz Refresh Rate and 256*128/256*256 dot Resolution for High-Quality Video Wall 0
Product Specifications
Item Indoor P4 Indoor P4 Indoor P4.81
Module
Panel Dimension 256mm(W) × 128mm(H) 320mm(W) × 160mm(H) 250mm(W) × 250mm(H)
Pixel pitch 4mm 4mm 4.81mm
Pixel Density 62500 dot/m² 62500 dot/m² 43264 dot/m²
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD2121 SMD2121 SMD2121
Pixel resolution 64 dot × 32 dot 80 dot × 40 dot 52 dot × 52 dot
Max power consumption 25W 26W 35W
Panel weight 0.2KG 0.3KG 0.47KG
Cabinet
Cabinet size 512mm×512mm×85mm 960mm×960mm×85mm 500×1000mm×85mm, 500×500×85mm
Cabinet Resolution 128 dot × 128 dot 240 dot × 240 dot 104 dot × 208 dot, 104 dot × 104 dot
Quantity of panel 8pcs 18pcs 8pcs, 4pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Diecasting aluminum cabinet / Iron cabinet Diecasting aluminum cabinet / Iron cabinet Diecasting aluminum cabinet / Iron cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 140/120 140/120 170/120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V40A
Max power capacity 1200 W/m² 700 W/m² 800W/m²
Average power 600 W/m² 350 W/m² 400W/m²
Technical Signal Index
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/16S 1/20S 1/13S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096×4096×4096 4096×4096×4096 4096×4096×4096
Brightness 800-1000 cd/m² 800-1000 cd/m² 800-1000 cd/m²
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 4-30M 4-30M 4-40M
Operating temperature -10°C~45°C -10°C~45°C -10°C~45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP43 IP43 IP43
Most in Kinglight and 3840 refresh rate, if need to change detail More Pixel Pitch and technical details, feel free to contact us
