제품 상세 정보:

원래 장소: 광동, 중국
브랜드 이름: LEDKING or OEM & ODM
모델 번호: RO-P391

결제 및 배송 조건:

최소 주문 수량: 1
가격: $145-165
최고의 가격 접촉

상세 정보
픽셀 피치: 3.91mm 픽셀 밀도: 65536 Dot/m2
픽셀 구성: 1R1G1B 패널 크기: 250mm ((W) * 250mm ((H)
패널 중량: 0.6kg 최대 전력 소비: 40W
캐비닛 크기: 500*1000mm*90mm, 500*500*90mm 캐비닛 해상도: 128 도트 * 256 도트, 128*128 도트
패널 수량: 8개, 4개 새로 고침 빈도: 1920-3840 HZ/S
명도: 4000 cd/m2 보기 각도: 170/ 120
작동 온도: -20C°~60C° IP 등급: IP65
수명: 100000 시간
강조하다:

Long Lifespan LED Video Wall Panel

,

Die Cast Aluminum Outdoor LED Display Screen

,

Full Color Rental LED Display

제품 설명

Outdoor P3.91 500×500mm Waterproof Giant P3 Stage LED Video Wall Panel Screen
Outdoor LED Display Screen with Long Lifespan 100000 Hours Die Cast Aluminum Cabinet and Full Color Display for Stage Events 0 Outdoor LED Display Screen with Long Lifespan 100000 Hours Die Cast Aluminum Cabinet and Full Color Display for Stage Events 1
Product Specifications
Item Outdoor P3 Outdoor P3.91 Outdoor P4
Module
Panel Dimension 192mm(W) × 192mm(H) 250mm(W) × 250mm(H) 256mm(W) × 128mm(H)
Pixel pitch 3mm 3.91mm 4mm
Pixel Density 111111 dot/m² 65536 dot/m² 62500 dot/m²
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD1921 SMD1921 SMD1921
Pixel resolution 64 dot × 64 dot 64 dot × 64 dot 64 dot × 32 dot
Max power consumption 30W 40W 32W
Panel weight 0.55KG 0.6KG 0.3KG
Item Outdoor P3 Outdoor P3.91 Outdoor P4
Cabinet
Cabinet size 576mm×576mm×90mm, 768×768×90mm 500×1000mm×90mm, 500×500×90mm 1024mm×768mm×90mm
Cabinet Resolution 192 dot × 192 dot, 256 dot × 256 dot 128 dot × 256 dot, 128×128 dot 256 dot × 192 dot
Quantity of panel 9pcs, 16pcs 8pcs, 4pcs 24pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Die-casting aluminum cabinet Die-casting aluminum cabinet Die-casting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 140°/120° 170°/120° 170°/120°
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 1100 W/m² 1200 W/m² 1550 W/m²
Average power 550 W/m² 600 W/m² 780 W/m²
Item Outdoor P3 Outdoor P3.91 Outdoor P4
Technical Signal Index
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/16S 1/16S 1/8S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096×4096×4096 4096×4096×4096 4096×4096×4096
Brightness 4500-5000 cd/m² 4000 cd/m² 5500-6000 cd/m²
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 3-30M 3-30M 4-40M
Operating temperature -10°C~45°C -20°C~60°C -10°C~45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP65 IP65 IP65
Contact us for more pixel pitch and technical details
