제품 상세 정보:

원래 장소: 광동, 중국
브랜드 이름: LEDKING or OEM & ODM
모델 번호: RO-P3.91 RO-P481

결제 및 배송 조건:

최소 주문 수량: 1
가격: $145-165
최고의 가격 접촉

상세 정보
모듈 차원: 192mm(W) * 192mm(H), 250mm(W) * 250mm(H), 256mm(W) * 128mm(H) 픽셀 피치: 3mm, 3.91mm, 4mm
픽셀 밀도: 65536 도트/m2, 62500 도트/m2 픽셀 구성: 1R1G1B
최대 전력 소비: 30W, 40W, 32W 패널 중량: 0.55KG, 0.6KG, 0.3KG
캐비닛 크기: 576mm*576mm*90mm, 768mm*768mm*90mm, 500mm*1000mm*90mm, 500mm*500mm*90mm, 1024mm*768mm*90mm 캐비닛 해상도: 192도트 * 192도트, 256도트 * 256도트, 128도트 * 256도트, 128도트 * 128도트, 256도트 * 192도트
가장 좋은 관점: 140/120, 170/120 스크린 전원 공급기: AC110V/220V - 5V60A
최대 전력 용량: 1100W/m2, 1200W/m2, 1550W/m2 새로 고침 빈도: 1920-3840 HZ/S
명도: 4500-5000cd/m2, 4000cd/m2, 5500-6000cd/m2 작동 온도: -10°C~45°C, -20°C~60°C
IP 보호 지수: IP65
강조하다:

500x500mm LED Video Wall

,

256*128/256*256 dot LED Advertising Display

,

1920Hz-3840Hz Outdoor LED Display Screen

제품 설명

P3.91 P4.81 500x500mm Module Screen Indoor Meeting Room SMD Wonderful Design Rental Panel Outdoor LED Advertising Display
500x500mm Outdoor LED Display Screen with 256*128/256*256 Dot Resolution and 1920Hz-3840Hz Refresh Rate 0 500x500mm Outdoor LED Display Screen with 256*128/256*256 Dot Resolution and 1920Hz-3840Hz Refresh Rate 1
Product Specifications
Item Outdoor P3 Outdoor P3.91 Outdoor P4
Module Specifications
Panel Dimension 192mm(W) * 192mm(H) 250mm(W) * 250mm(H) 256mm(W) * 128mm(H)
Pixel pitch 3mm 3.91mm 4mm
Pixel Density 111111 dot/m2 65536 dot/m2 62500 dot/m2
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD1921 SMD1921 SMD1921
Pixel resolution 64 dot * 64 dot 64 dot * 64 dot 64 dot * 32 dot
Max power consumption 30W 40W 32W
Panel weight 0.55KG 0.6KG 0.3KG
Cabinet Specifications
Cabinet size 576mm*576mm*90mm, 768*768*90MM 500*1000mm*90mm, 500*500*90mm 1024mm*768mm*90mm
Cabinet Resolution 192 dot * 192 dot, 256 dot * 256 dot 128 dot * 256 dot, 128*128 dot 256 dot * 192 dot
Quantity of panel 9pcs, 16pcs 8pcs, 4pcs 24pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Diecasting aluminum cabinet Diecasting aluminum cabinet Diecasting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 140/120 170/120 170/120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 1100 W/m2 1200 W/m2 1550 W/m2
Average power 550 W/m2 600 W/m2 780 W/m2
Technical Specifications
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/16S 1/16S 1/8S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096*4096*4096 4096*4096*4096 4096*4096*4096
Brightness 4500-5000 cd/m2 4000 cd/m2 5500-6000 cd/M2
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 3-30M 3-30M 4-40M
Operating temperature -10°C~45°C -20°C~60°C -10°C~45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP65 IP65 IP65
Most in Kinglight and 3840 refresh rate, if need to change detail More Pixel Pitch and technical details, feel free to contact us
