Outdoor LED Display Screen with Die Cast Aluminum Cabinet Full Color and High Brightness for Advertising

최소 주문 수량:	1
가격:	$456-476

최고의 가격 접촉

상세 정보
픽셀 피치:	5mm, 6mm, 6.67mm	픽셀 밀도:	40000 도트/m2, 27777 도트/m2, 22477 도트/m2
픽셀 구성:	1R1G1B	최대 전력 소비:	40W, 29W, 43W
패널 중량:	0.45KG, 0.35KG, 0.45KG	캐비닛 크기:	960mm960mm90mm, 576mm576mm90mm, 768mm768mm90mm
캐비닛 해상도:	192도트 * 192도트, 96도트 * 96도트, 128도트128도트, 144도트144도트	가장 좋은 관점:	170/120, 140/120
스크린 전원 공급기:	AC110V/220V - 5V60A	최대 전력 용량:	976W/m2, 1050W/m2, 1350W/m2
새로 고침 빈도:	1920-3840 HZ/S	명도:	5000-5500mcd/m2, 4000-5000cd/m2
제어 거리:	< 1억	작동 온도:	-10°C~45°C
작동 습도:	10-90%
강조하다:	Die Cast Aluminum Cabinet LED Video Wall , Full Color Outdoor LED Display Screen , High Brightness Digital Signage Billboard

제품 설명

960×960 P5 P6.67 P8 P10 Fixed Outdoor LED Video Wall Display

Product Specifications

Module Specifications

Item	Outdoor P5	Outdoor P6	Outdoor P6.67
Panel Dimension	320mm(W) × 160mm(H)	192mm(W) × 192mm(H)	320mm(W) × 160mm(H)
Pixel pitch	5mm	6mm	6.67mm
Pixel Density	40000 dot/m²	27777 dot/m²	22477 dot/m²
Pixel configuration	1R1G1B	1R1G1B	1R1G1B
Specification	SMD1921	SMD3535	SMD3535
Pixel resolution	64 dot × 32 dot	32 dot × 32 dot	48 dot × 48 dot
Max power consumption	40W	29W	43W
Panel weight	0.45KG	0.35KG	0.45KG

Cabinet Specifications

Item	Outdoor P5	Outdoor P6	Outdoor P6.67
Cabinet size	960mm×960mm×90mm	576mm×576mm×90mm, 768mm×768mm×90mm	960mm×960mm×90mm
Cabinet Resolution	192 dot × 192 dot	96 dot × 96 dot, 128dot×128dot	144dot×144dot
Quantity of panel	18pcs	9pcs, 16pcs	18pcs
Hub connecting	HUB75-E	HUB75-E	HUB75-E
Cabinet Material	Diecast aluminum cabinet	Diecast aluminum cabinet	Diecast aluminum cabinet
Maintenance Method	Front/Back service	Front/Back service	Front/Back service
Best viewing angle	170/120	140/120	140/120
Screen power supply	AC110V/220V - 5V60A	AC110V/220V - 5V60A	AC110V/220V - 5V60A
Max power capacity	976W/m²	1050W/m²	1350W/m²
Average power	488W/m²	525W/m²	675W/m²

Technical Specifications

Item	Outdoor P5	Outdoor P6	Outdoor P6.67
Driving IC	ICN 2037 / 2153	ICN 2037 / 2153	ICN 2037 / 2153
Scan Rate	1/8S	1/8S	1/6S
Refresh frequency	1920-3840 HZ/S	1920-3840 HZ/S	1920-3840 HZ/S
Display color	4096×4096×4096	4096×4096×4096	4096×4096×4096
Brightness	5000-5500 mcd/m²	4000-5000 cd/m²	4000-5000 cd/m²
Life span	100000 Hours	100000 Hours	100000 Hours
Control distance	< 100M	< 100M	< 100M
Best viewing distance	5-40M	6-40M	6-40M
Operating temperature	-10°C ~ 45°C	-10°C ~ 45°C	-10°C ~ 45°C
Operating Humidity	10-90%	10-90%	10-90%
IP protective index	IP65	IP65	IP65
